BD Xtrude Transmission Cooler Ford F250 / F350 Super Duty (03-16) Complete Kit 1/2 Lines w/ Fan – 1030606-1/2

Description

Fitment Information

• Ford F250 Super Duty 5.4L (2003, 2004, 2006, 2007, 2008, 2009, 2010)
• Ford F250 Super Duty 6.0L (2003, 2004, 2006, 2007)
• Ford F250 Super Duty 6.2L (2011, 2012, 2013, 2014, 2015, 2016)
• Ford F250 Super Duty 6.4L (2008, 2009, 2010)
• Ford F250 Super Duty 6.7L (2011, 2012, 2013, 2014, 2015, 2016)
• Ford F250 Super Duty 6.8L (2003, 2004, 2006, 2007, 2008, 2009, 2010)
• Ford F250 Super Duty 7.3L (2003)
• Ford F350 Super Duty 5.4L (2003, 2004, 2006, 2007, 2008, 2009, 2010)
• Ford F350 Super Duty 6.0L (2003, 2004, 2006, 2007)
• Ford F350 Super Duty 6.2L (2011, 2012, 2013, 2014, 2015, 2016)
• Ford F350 Super Duty 6.4L (2008, 2009, 2010)
• Ford F350 Super Duty 6.7L (2011, 2012, 2013, 2014, 2015, 2016)
• Ford F350 Super Duty 6.8L (2003, 2004, 2006, 2007, 2008, 2009, 2010)
• Ford F350 Super Duty 7.3L (2003)

Note

• Intended to be used in conjunction with factory transmission coolers and not as stand-alone units

Specs & Features

• 22% more cooling over other designs
• 200 Micro Extruded passages
• Large surface area to transfer heat for external air flow cooling
• Turbulent oil flow design promotes a more complete cooling
• Large 5/8-inch ports prevents inlet/outlet restriction
• Furnace brazed rails have been tested to 300psi of pressure
• Thermostatically controlled 80-watt, 10-inch, 800 CFM electric fan
• 33,930 BTU/HR and in excess of 30,000 GVW!
• Kits complete with all fittings, clamps, hoses and hardware
• Build-It-Yourself galvanized bracket kit for quick and easy installation – no wasting time fabricating brackets out of scrap metal
• The pre-wired loomed harness with fuse and relay comes with plug-in connectors
• Dodge 47RH / 47RE / 48RE / 68RFE – 1/2-inch Cooler Lines
• Ford 5R110/6R140 – 1/2-inch Cooler Lines)

Warranty

• Parts: 24 months or 24, 000 Miles

Product Description

Coolers, providing 22% more cooling over other designs. The 200 Micro Extruded passages provide a large surface area to transfer heat for external air flow cooling while turbulent oil flow design promotes a more complete cooling. Large 5/8-inch ports prevents inlet/outlet restriction and furnace brazed rails have been tested to 300psi of pressure. The thermostatically controlled 80-watt, 10-inch, 800 CFM electric fan offers ultimate automatic oil temperature control. This combination gives BD’s Xtruded Transmission Oil Cooler a rating of 33,930 BTU/HR and in excess of 30,000 GVW! Xtruded Transmission Oil Cooler packages come complete with all fittings, clamps, hoses, hardware and a Build-It-Yourself galvanized bracket kit for quicker and cleaner installation – no wasting time fabricating brackets out of scrap metal. The pre-wired loomed harness with fuse and relay comes with OEM style sealed connectors to resist elements and give factory-like install look.
