ICON Vehicle Dynamics FRDK_K53007 ICON 2005-2015 Toyota Tacoma 0-3.5″ Lift/2016-2023 Tacoma 0-2.75″ Lift Stage 7 Suspension System Billet UCA

Description

This system features upper control arms with ICON’s patented Delta Joint. The Delta Joint is a heavy-duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball. While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application – exposure to the elements. The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint. Metal on metal construction and a greaseable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation. What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.r

• Increased wheel travel and ride quality over stock

r

• Billet aluminum UCAs for added strength, durability, and on-vehicle caster/camber adjustment for optimum drivability

r

• UCAs feature the patented (U.S. Pat. 10,731,700) Delta Joint

r

• 2.5 Aluminum Series Omega Bypass rear shocks with compression and rebound adjustability provide the ultimate in ride control

r

• Add-A-Leaf Kit replaces OE overload leaf spring for more compliant ride quality and 1.5″ of rear lift

r

• Vehicle specific tuned front and rear shocks for superior shock damping and control

r

• 2.5 Series front coilovers with remote reservoirs for improved shock cooling and consistent performance under hard use

r

• Adjustable coilovers provide up to 3.5″ of front lift height on 2005-2015 models and up to 2.75″ on 2016-2023 models

r

• Front coilovers equipped with CDC Valves for 10 settings of compression damping adjustment, from soft to hard

r

• Extended Travel coilovers offer maximum wheel travel

r

• 6061 aircraft grade aluminum CNC machined components

r

• Corrosion resistant CAD plated coilover shock bodies with 7/8″ shafts

r

• FK Rod End bearings for extended longevity and minimal deflection

r

rr

Attributes:

r

r
• GTIN: 00840103416472

r

• Brand Name: ICON Vehicle Dynamics

r

• 2064: Steel

r

• 2371: Yes

r

• 30: Yes

r

• 3096: Black

r

• 3097: Yes

r

• 3390: Performance

r

• 6111: 3

r

• 7325: 2

r

• Add-On Part: 191003 – ICON SHORT 2.5 COIL WRAP W/LOGO PAIR (11.25-12.25)

r

• Adjustable Damping: Yes

r

• Damping Adjustment Type: Manual

r

• Front Spring Rate 1: 650

r

• Front Spring Rate Type: Linear

r

• Maximum Lift Front: 3.5

r

• Maximum Lift Rear: 1.5

r

• Minimum Lift Front: 0

r

• OEM Wheels & Tires Fitment: Yes

r

• Rear Spring Rate Type: Linear

r

• Recommended Aftermarket Tires: 33″ x 11.50″ (Larger tires may fit but fender trimming and modifications will be required.)

r

• Recommended Aftermarket Wheels: ICON Alloys – 17×8.5 with 4.75” Backspace / 0mm Offset

r

rr

Extended Information:

r

r
• Country of Origin: US

r

• Emissions : 4

r

• Life Cycle Status: Available To Order

r

rr

Packing Information:

r

r
• Quantity of Each: 1.0

r

• Package UOM: EA

r

• Dimension: 27.0000 x 12.0000 x 6.0000 inches

r

• Weight: 151.0000 lb
