Description
Fitment Information
- Universal – Requires fabrication and/or custom mounting
Specifications:
- Filler Hose Requirement: 1.5″
- Flange Outer Diameter: 4.75″
- Bolt Circle Diameter: 4.25″ PCD
- Height: 4.08″ (Dry Break to Barb)
- Mate: 20-0496 Dry Break, 1.5in, Male
What’s included?
Includes a 1.5in female dry break as well as a gasket, stainless steel hardware, an aluminum housing and aluminum nut ring.
Product Description
Designed for remote mounting to an external surface such as a fender. Requires a 77mm (3.03″) hole to be fabricated. The vented fuel cap has roll-over protection in case the vehicle ever becomes inverted. The components, materials, and seals are compatible with all fuel types (unleaded and leaded gasoline, diesel, AV gas, methanol, ethanol, E15, E85, etc.).
The o-ring sealed 1.5″ barbed outlet is interchangeable. By simply removing 6 screws, a different outlet adapter (sold separately) can be installed.
